Home Product Isostatic Graphite

Isostatic Graphite

lsostatic pressure isotropic graphite is made of high-quality asphalt coke,petroleum coke as raw material and pitch as binder by grinding,batching,mixing,secondary grinding, isostatic pressing molding,baking,impregnation,graphitization,purification and other processes.lt has the characteristics of good isotropic,fine and uniform structure,high mechanical strength,good high temperature resistance, strong chemical corrosion resistance, good electrical and thermal conductivity and excellent machining performance,widely to be used in solar photovoltaic,semiconductor,metal continuous casting,precious metal smelting,and other industries.

info@yecarbon.com

Related Products

Product Catalog

Technical Specification of Isotropic Graphite

Brand Trademark	Bulk density ≥g/cm³	Resistivity uΩ·m	Thermal conductivity W/m·k	Coefficient of thermal expansion ×10-6/℃	Shore hardness HSD	Flexural strength MPA	Compressive strength MAP	Elastic modulus GPA	Ash PPM	Granularity um
YTS-1	1.78	13-18	70	5.0	65	≥45	≥95	11.0	≤200	15
YTS-2	1.78	13-18	70	5.0	65	≥45	≥95	11.0	≤200	15
YTS-3	1.78	13-18	70	5.0	65	≥45	≥95	11.0	≤200	15
TYS-4	1.78	13-18	70	5.0	65	≥45	≥95	11.0	≤200	15
YTS-5	1.78	13-18	70	5.0	65	≥45	≥95	11.0	≤200	15
YTS-6	1.78	13-18	70	5.0	65	≥45	≥95	11.0	≤200	15
YTE-1	1.82	13-16	76.9	5.0	75	≥80	≥165	11.0	≤100	5
YTE-2	1.78	13-16	76.9	5.0	75	≥80	≥165	11.0	≤100	7
YTE-3	1.80	13-16	76.9	5.0	75	≥80	≥165	11.0	≤100	10
YTI-1A	1.85	10-13	133	4.8	60	≥45	≥90	11.5	≤300	20
YTI-1B	1.80	11-13	121	4.8	55	≥40	≥86	10.0	≤300	20
YTI-1C	1.80	11-15	120	5.0	58	≥47	≥88	11.6	≤300	20
YTI-1D	1.75	11-15	108	4.8	54	≥40	≥82	10.5	≤300	20
YTI-4S	1.80	12.5	121	4.7	55	≥37	≥80	11.5	≤500	20
YTI-5L	1.85	11.5	140	4.8	62	≥47	≥95	11.5	≤400	20
YTI-8L	1.80	11.0	130	4.3	50	≥40	≥86	12.5	≤400	20
YTI-9L	1.88	13.0	120	5.0	65	≥50	≥105	9.5	≤500	20
EDM-9	1.90	14.0	85	6.8	90	80	160	14.0	5	6
EDM-10	1.83	12.0	100	5.3	66	52	110	12.5	500	10
EDM-80	1.75	13.0	100	6.0	60	50	100	10.0	500	10
EDM-60	1.88	13.0	120	6.0	75	80	160	12.5	500	6
M32	1.86	14.0		5.5	95	80	165	13.5		3
M33	1.72	20.0		6.0	85	65	155	12.0		3
YTI-2G	1.80	12.0	121	4.5	55	40	86	10.0	20	15
YTI-3G	1.85	12.0	133	5.2	60	45	90	11.5	20	15
YTI-47G	1.85	12.0	116	4.8	65	48	102	12.2	20	15
YTI-S1	1.80	12.5	105	4.5	58	45	90	10.0	5	10
YTI-S2	1.82	11.0	120	4.8	55	50	105	10.0	5	10
YTI-S3	1.78	11.0	120	3.8	55	40	85	10.0	5	10
